Nickel-metal hydride rechargeable battery

SHENZHEN BOYING ENERGY CO.LTD

Ni-MH BATTERY SPECIFICATION - STANDARD INDUSTRIAL

NOTE:

1.The capacities obtained at 0.1C charge&0.2C discharge at the temperature of 25℃

2.BY recommends for standard charing:0℃～45℃ and for discharge;－20℃～+50℃,Strict controlrecommended over rapid charge.

BY Model	Volt/（V)	Capacity/（mAh）		Dimensions/（mm）		Standard Charge		Rapid charge		Ri	Wt.
		Rated	Min.	H	Dia.	mA	h	mA	min	mΩ	App.
		Rated	Min.	H	Dia.	mA	h	mA	min	mΩ	g
2/3AAA300	1.2	300	280	28.5±0.5	10.0+0.4	30	16	300	72	≤50	7.50
2/3AAA400	1.2	400	380	28.5±0.5	10.0+0.4	40	16	400	72	≤50	8.50
AAA500	1.2	500	470	42.5±0.5	10.0+0.4	50	16	500	72	≤40	10.00
AAA550	1.2	550	520	42.5±0.5	10.0+0.4	55	16	550	72	≤40	10.50
AAA600	1.2	600	570	42.5±0.5	10.0+0.4	60	16	600	72	≤40	11.00
AAA700	1.2	700	660	44.0±0.5	10.1+0.4	70	15	700	72	≤35	11.50
AAA800	1.2	800	750	44.0±0.5	10.1+0.5	80	15	400	140	≤35	12.00
AAA850	1.2	850	800	44.0±0.5	10.1+0.5	85	15	400	150	≤35	12.50
2/3AA700	1.2	700	670	28.5±0.5	13.8+0.5	70	16	700	72	≤40	13.00
4/5AA1200	1.2	1200	1150	42.5±0.5	13.8+0.5	120	16	1200	72	≤40	21.00
4/5AA1500	1.2	1500	1400	42.5±0.5	13.9+0.5	150	16	1500	72	≤40	25.00
AA600	1.2	600	570	48.5±0.5	13.8+0.5	60	16	600	72	≤35	15.00
AA800	1.2	800	770	48.5±0.5	13.8+0.5	80	16	800	72	≤35	17.00
AA1000	1.2	1000	950	48.5±0.5	13.8+0.5	100	16	1100	72	≤35	20.00
AA1200	1.2	1200	1150	48.5±0.5	13.9+0.5	120	16	1200	72	≤35	21.00
AA1300	1.2	1300	1250	48.5±0.5	13.9+0.5	130	16	1300	72	≤35	22.00
AA1400	1.2	1400	1350	48.5±0.5	13.9+0.5	140	16	1400	72	≤35	24.00
AA1500	1.2	1500	1450	48.5±0.5	13.9+0.5	150	16	1500	72	≤30	25.00
AA1600	1.2	1600	1550	48.5±0.5	13.9+0.5	160	16	1600	72	≤30	25.50
AA1800	1.2	1800	1750	49.5±0.5	14.1+0.5	180	16	900	140	≤30	27.00
AA2000	1.2	2000	1900	49.5±0.5	14.1+0.5	200	15	1000	140	≤30	28.50
AA2100	1.2	2100	2000	49.5±0.5	14.1+0.5	210	15	1050	140	≤30	29.00
AA2200	1.2	2200	2100	49.5±0.5	14.1+0.5	220	15	1100	140	≤30	29.50
2/3A1100	1.2	1100	990	28.5±0.5	16.6+0.5	110	16	1100	72	≤30	18.50
2/3A1200	1.2	1200	1150	28.5±0.5	16.6+0.5	120	16	1200	72	≤30	19.50
2/3A1500	1.2	1500	1400	29.5±0.5	16.6+0.5	150	16	1500	72	≤30	21.00
4/5A1800	1.2	1800	1750	42.5±0.5	16.6+0.5	180	16	1800	72	≤30	31.00
4/5A2000	1.2	2000	1900	42.5±0.5	16.6+0.5	200	16	1000	140	≤30	33.00
4/5A2200	1.2	2200	2100	42.5±0.5	16.6+0.5	220	15	1100	140	≤30	35.00
A2100	1.2	2100	2000	49.5±0.5	16.6+0.5	210	16	1050	140	≤25	36.00
A2400	1.2	2400	2300	49.5±0.5	16.6+0.5	240	16	1200	140	≤25	39.00
A2600	1.2	2600	2500	49.5±0.5	16.6+0.5	260	16	1300	140	≤25	41.00
4/3A3000	1.2	3000	2900	66.5±0.5	16.6+0.5	300	15	1500	140	≤25	48.00
4/3A3300	1.2	3300	3200	66.5±0.5	16.6+0.5	330	15	1650	140	≤25	50.00
4/3A3500	1.2	3500	3350	66.5±0.5	16.6+0.5	350	15	1750	140	≤25	52.00
4/3A3800	1.2	3800	3650	66.5±0.5	16.6+0.5	380	15	1900	140	≤25	55.00
67AF3800	1.2	3800	3700	67.0±0.5	18.0+0.5	380	16	1900	140	≤25	57.00
67AF4000	1.2	4000	3900	67.0±0.5	18.0+0.5	400	15	2000	140	≤25	62.00
67AF4200	1.2	4200	4100	67.0±0.5	18.0+0.5	420	15	2100	140	≤25	62.00
67AF4500	1.2	4500	4300	67.0±0.5	18.0+0.5	450	15	2250	140	≤25	64.00
4/5SC2200	1.2	2200	2100	33.5±0.5	22.0+0.6	220	15	1100	140	≤25	47.00
SC2500	1.2	2500	2400	42.5±0.5	22.0+0.6	250	16	1250	140	≤25	53.00
SC3000	1.2	3000	2900	42.5±0.5	22.0+0.6	300	16	1500	140	≤25	56.00
SC3600	1.2	3600	3500	42.5±0.5	22.4+0.6	360	16	1800	140	≤25	62.00
C3000	1.2	3000	2900	49.0±0.5	25.0+0.6	300	16	1500	140	≤20	66.00
C3500	1.2	3500	3400	49.0±0.5	25.0+0.6	350	16	1750	140	≤20	72.00
C4000	1.2	4000	3850	49.0±0.5	25.0+0.6	400	16	2000	140	≤15	80.00
C4500	1.2	4500	4350	49.0±0.5	25.0+0.6	450	16	2250	140	≤15	84.00
C4700	1.2	4700	4550	49.0±0.5	25.0+0.6	470	16	2350	140	≤15	86.50
C5000	1.2	5000	4800	49.0±0.5	25.0+0.6	500	16	2500	140	≤15	88.00
D6000	1.2	6000	5900	60.0±0.5	32.0+0.6	600	16	3000	144	≤12	120.00
D7000	1.2	7000	6900	60.0±0.5	32.0+0.6	700	16	3500	140	≤12	135.00
D8000	1.2	8000	7700	60.0±0.5	32.0+0.6	800	15	4000	144	≤12	155.00
D9000	1.2	9000	8700	60.0±0.5	32.0+0.6	900	15	4500	140	≤12	165.00
D10000	1.2	10000	9600	60.0±0.5	32.0+0.6	1000	15	3000	240	≤10	180.00
F10000	1.2	10000	9800	90.0±0.5	32.0+0.6	1000	15	2000	360	≤10	215.00
F12000	1.2	12000	11500	90.0±0.5	32.0+0.6	1200	15	2400	360	≤10	230.00
F13000	1.2	13000	12500	90.0±0.5	32.0+0.6	1300	15	2600	360	≤10	240.00
F14000	1.2	14000	13500	90.0±0.5	32.0+0.6	1400	15	2800	360	≤10	245.00
F15000	1.2	15000	14500	90.0±0.5	32.0+0.6	1500	15	3000	360	≤10	255.00
